| Features: |
- 2688x1520 @ 20fps
- 4 Megapixel High Resolution
- 1/3" Progressive Scan CMOS
- 4.0mm Fixed Lens
- 0.01 lux @ F2.0 (AGC on), 0 lux with IR
- 30 IR LED
- IR distance up to 100ft / 30m
- Mechanical IR Cut Filter (ICR)
- 3D DNR & True WDR & BLC
- Max. 5W
- 12V DC / POE (802.3af)
- IP66 Rating
*This Product is available for  OR  service. Click here for more details
|
| Model |
NI4B-V040 |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Horizontal Resolution |
4MP |
| Max. Image Resolution |
2688×1520 |
| Frame Rate |
20fps (2688×1520), 30fps (1920×1080) |
| Shutter Time |
1/30s ~ 1/100,000s |
| Minimum Illumination |
0.01 lux @ (F1.2, AGC ON), 0 lux with IR |
| Day & Night |
Built-in Mechanical IR Cut Filter (ICR) |
| Digital Noise Reduction |
3D DNR |
| Wide Dynamic Range |
True WDR 120dB |
| IR LED |
30pcs IR |
| IR Distance |
100ft / 30m |
| Lens Type |
4mm @ F2.0, Angle of view: 75.8° |
| Video Compression |
H.264 / MJPEG / H.264+ |
| Dual Stream |
Yes |
| Image Settings |
Saturation, brightness, contrast, sharpness adjustable through client software or web browser |
| BLC |
Yes, Zone optional |
| Network Storage |
NAS |
| Alarm Trigger |
Motion detection, tampering alarm, network disconnect, IP address conflict, storage exception |
| Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos |
| System Compatibility |
ONVIF, PSIA, CGI |
| General Functionalities |
User Authentication, reset button, flickerless, dual stream, heartbeat, mirror, watermark |
| Communication Interface |
1 RJ45 10M/ 100 M Ethernet interface |
| Power Source |
12 VDC ± 10%, PoE (802.3af) |
| Power Consumption |
Max. 5W |
| IP Rating |
IP66 Rating |
| Operating Temperature |
-22°F ~ 140°F / -30°C ~ 60°C |
| Humidity |
95% or less (non-condensing) |
| Dimension |
2.4(W) x 3(H) x 5.5(L) inches / 62(W) x 76.2(H) x 139.7(L) mm |
| Net Weight |
0.66 lbs / 0.3 kg |
*Specifications are subject to change without notice.
MADE IN CHINA
Package Contents:
- One (1) Network IP Camera
- Three (3) Mounting Screws & Anchors
- One (1) RJ45 Weather Proof Boot
- One (1) User Manual
*Manufacturer's Three (3) Year Warranty
|
